C26000 Cartridge Brass · C27200 Basis Brass · C36000 Free Cutting Brass · C38500 Free Machining Brass · C46400 Naval Brass
Brass is a metal alloy made of copper and zinc; the proportions of zinc and copper can be varied to create a range of brasses with varying properties. It is a substitutional alloy: atoms of the two constituents may replace each other within the same crystal structure.
Brass, which is an alloy metal made of copper and zinc, by varying the proportions of copper and zinc, the properties of the brass can be changed, allowing hard and soft brasses. Brass has higher malleability than bronze or zinc. The relatively low melting point of brass (900 to 940 °C, 1,650 to 1,720 °F, depending on composition) and its flow characteristics make it a relatively easy material to cast. The density of brass is 8.4 to 8.73 grams per cubic centimetre (0.303 to 0.315 lb/cu in). Mumbadevi Steel India (MSI) currently stocks following 4 brass alloys. Brass Supplier Mumbadevi Steel India (MSI) offers high quality Brass in forms like Brass Seamless Pipe, Brass Welded Pipe, Brass Seamless Tube, Brass Welded Tube, Brass Flange, Brass Pipe Flange, Brass Round Bar, Brass Bar, etc. Mumbadevi Steel India (MSI) Specializes in grades like CZ106, CZ108, CZ112, CZ121 with UNS C26000, UNS C27200, UNS C36000, UNS C38500, UNS C46400 and other names like Cartridge Brass, Basis Brass, Naval Brass, Free Machining Brass, Spinning Brass, Spring Brass, Naval Bronze, Free Cutting Brass. Mumbadevi Steel India (MSI) stocks a Brass in forms of Pipe, Tube, Flanges and Round Bar in all sizes and forms. We export to more than Taiwan, India, United States, Brazil, United Kingdom, Italy, Russia, Canada, Germany, United Arab Emirates, Indonesia, France, South Korea, Netherlands, Mexico, Singapore, Spain, Malaysia, Australia, Japan, Thailand, Iran, Saudi Arabia, Vietnam, Poland, Sweden, Turkey, Philippines, Romania, Chile, Colombia, South Africa, Belgium, Kuwait, Qatar, Czechia, Greece, Hong Kong, New Zealand, Denmark, Switzerland, Oman.
Cartridge Brass referred to as spinning brass, spring brass, CW505L / CZ106 is an alpha brass, with zinc content of 30% and rest being copper. CW505L / CZ106 exhibits an excellent combination of strength and ductility for the alpha phase brasses. C26000 grade is used for its outstanding deep drawing properties and excellent cold workability. C260 Brass is not very machinable, but is a great combination of formability and workability. C26000 is used for architecture, drawn and spun containers and shapes, electrical terminals and connectors, door handles, plumbers hardware. C26000 has good corrosion resistance to weathering and very good resistance to many chemicals. It may undergo dezincification in stagnant or slowly moving salt solutions, brackish water or acidic solutions.
Industry Names: Cartridge Brass, Arsenical Brass, Spinning Brass, Spring Brass.
Specifications: CW505L, CZ106, C26000, CuZn30.
Chemical Composition: Copper(Cu)-71.5%, Zinc(Zn) - 31.5%, Iron(Fe) - 0.05% max, Lead(Pb) - 0.07% max.
Key Features: Superb cold forming properties, Excellent deep drawing characteristics, Good Corrosion resistance, Optimum combination of strength and ductility for alpha brasses.
Typical Applications Include: Architecture, grillwork, appliances, drawn & spun containers and components, radiator cores and tanks, electrical terminals, plugs and lamp fittings, locks, door handles, name plates, plumbers hardware, fasteners, cartridge cases, cylinder liners for pumps.
Available Forms: Mumbadevi Steel India (MSI) supplies Cartridge Brass / Spinning Brass / Spring Brass in forms like Pipe, Tube, Rectangular Tubes, Custom Tubes, Flanges, Round Bar, Flat Bar.
Basis Brass commonly referred to as CW508L / CZ108, is a 37% zinc containing brass. Predominantly an alpha brass it is one of the most popular grades due to its hot and cold working capabilities. C27200 is often used for general purpose applications and forming operations when very good bending properties are required. It also offers a very good general corrosion resistance in many natural atmospheres, a reasonable machinability and good cold heading properties.
Industry Names: Basis Brass.
Specifications: CW508L, CZ108, C27200, CuZn37.
Chemical Composition: Copper(Cu)-65.0%, Zinc(Zn) - 37.0%, Iron(Fe) - 0.05% max, Lead(Pb) - 0.30% max.
Key Features: Good hot and cold forming properties, Good Corrosion resistance, Very good cold heading attributes, Good strength properties.
Typical Applications Include: Heat Exchangers, Lamp Caps, Lamp-holder, Switch Components, General Copper-smithing Work, Chains, Eyelets, Fasteners, Hinges, Locks, Instrument Covers, Pins, Rivets, Screws, Springs, Radiator Tanks And Torch Cases.
Available Forms: Mumbadevi Steel India (MSI) supplies Basis Brass in forms like Pipe, Tube, Rectangular Tubes, Custom Tubes, Flanges, Round Bar, Flat Bar.
Naval Brass commonly known as CW712R / CZ112 is due to its improved corrosion resistance in marine environments. The general composition is 60% copper, 39% zinc with a 1% tin addition which gives an improved corrosion resistance and also gives a harder and stronger duplex structure to improve the mechanical properties. The improvement in corrosion resistance enables the material to be used in both seawater and other mildly aggressive media, C46400 also offers better strength levels than many of the basic alpha brasses combined with an excellent hot formability. Used primarily in applications where corrosion resistance is important, the material has a small amount of tin added to help deal with corrosion, especially in seawater.
Industry Names: Naval Brass, Naval Bronze.
Specifications: CZ112, CW712R, C46400, CuZn36Sn1.
Chemical Composition: Copper(Cu)-63.5%, Zinc(Zn)-39.25%, Iron(Fe)-0.10% max, Tin(Sn)-1.00%.
Key Features: Very good corrosion resistance in marine environments, Excellent hot formability, Good Strength, Retention of properties at cryogenic temperatures.
Typical Applications Include: Heat Exchanger Tube Plates, Bolts, Nuts, Rivets, Marine Hardware and Fasteners.
Available Forms: Mumbadevi Steel India (MSI) supplies Naval Brass / Naval Bronze in forms like Pipe, Tube, Rectangular Tubes, Custom Tubes, Flanges, Round Bar, Flat Bar.
Free Machining Brass with European grade CW614N / CZ121 consisting of a duplex structure and a 3% lead addition. The particles of lead are finely dispersed throughout the microstructure and acts as both a lubricant and a chip breaker to give the alloy its free machining characteristics. The machinability rating of 100% for C36000 is the standard against which all other copper alloys are rated. It is the most widely used of all the brasses due to its suitability for high speed machining operations and also the manufacture of intricate parts. Its combination of machinability, thread rolling and knurling characteristics, combined with its good strength, an ease of soldering / brazing and a high resistance to corrosion makes it the ideal choice for many brass components throughout industry. The presence of lead in the alloy creates a highly machinable material that can easily be cut and shaped into whatever you need. Free Machining Brass is not so good, however, at forming operations.
Industry Names: Free Machining Brass, Free Cutting Brass.
Specifications: CZ121, CW614N, C36000, C38500, CuZn39Pb3.
Chemical Composition: Copper(Cu)-58.5%, Zinc(Zn)-35.5%, Iron(Fe)-0.35% min, Lead (Pb)-3.5%.
Key Features: The Highest Machinability of any Copper Alloy, Excellent hot formability, Good Corrosion Resistance.
Typical Applications Include: Nuts, Bolts, Threaded Parts, Terminals, Jets, Taps, Injectors, Valve Bodies, Balance Weights, Pipe Water Fittings.
Available Forms: Mumbadevi Steel India (MSI) supplies Free Machining Brass / Free Cutting Brass in forms like Pipe, Tube, Rectangular Tubes, Custom Tubes, Flanges, Round Bar, Flat Bar.
Mumbadevi Steel India (MSI) specializes in offering hard to find Brass items in large or small quantity. Contact Us Today ! for best quote on Cartridge Brass / Basis Brass / Naval Brass / Free Machining Brass / Free Cutting Brass.
Brass made up of copper and zinc, the proportions of zinc and copper can be varied to create a range of brasses like Cartridge Brass, Basis Brass, Naval Brass, Free Machining Brass
Other Names: CW505L, CZ106, C26000, CuZn30, CW508L, CZ108, C27200, CuZn37, CZ112, CW712R, C46400, CuZn36Sn1, CZ121, CW614N, C36000, C38500, CuZn39Pb3.
Category: Brass > Cartridge Brass · Basis Brass · Naval Brass · Free Machining Brass · Spinning Brass · Spring Brass · Naval Bronze · Free Cutting Brass.
Brand: Mumbadevi Steel India (MSI)
Manufacturer: Mumbadevi Steel India (MSI)
Available Grades in Brass
Brass Specifications and Standards
|Grade Name||UNS Number||AS Number||JIS Number||ISO Designation||British Designation||BSEN Designation||Other Names|
|Cartridge Brass||UNS C26000||AS 260||JIS C2600||CuZn30||CZ106||CW505L||260 Brass / C260 Cartridge Brass|
|Basis Brass||UNS C27200||AS 272||JIS C2720||CuZn37||CZ108||CW508L||Common Brass|
|Naval Brass||UNS C46400||AS 464||JIS C4640||CuZn36Sn1pb||CZ112||CZ112||Naval Bronze|
|Free Machining Brass||UNS C36000 / C38500||AS 360 / 385||-||CuZn39Pb3||CZ121||CW614N||Free Cutting Brass|
