Zeron 100 with UNS S32760 is a super duplex stainless steel containing 25% Cr, 4% Mo, and 7% Ni with addition of Copper and Tungsten, resulting excellent corrosion resistance, designed for acid leach mining applications and other industries where sulfuric acid is encountered.
Super Duplex 4501 also known as Super Duplex S32760, Duplex 4501, 25Cr Duplex and Zeron 100, is a super duplex stainless steel with a composition of 25% chromium, 3.6% molybdenum, 1.0 copper and 0.7% tungsten for excellent pitting resistance to various chlorides and organics acids. Super Duplex S32760 has excellent corrosion resistance combined with high strength. Zeron 100 is made to meet a minimum pitting resistance equivalent (PREn) value of 40. The ferritic structure and alloy additions, such as nitrogen provide yield strengths that are twice that of 300 series stainless steels. The addition of Copper in Super Duplex S32760 provides good resistance to sulfuric acid, Thus, Super Duplex 4501 is used in acid leach mining applications, steel pickling and other industries where sulfuric acid is encountered. Super Duplex UNS S32760 is among the most common super duplex grade in the market. Zeron 100 is a super duplex stainless steel especially designed for service in aggressive chloride-containing environments and has additions of W and Cu compared to UNS S32750. Duplex 4501 has very good resistance to localized corrosion and stress corrosion cracking in combination with high mechanical strength. 25Cr Super Duplex is a super duplex stainless steel supplied in the hot worked and solution annealed condition. As a super duplex stainless steel, it combines the desirable aspects of both austenitic and ferritic grades. Duplex 4501 provides higher strength than both austenitic and 22% Cr duplex stainless steels, and is listed in NACE MR 0175 for sour service and ASME for pressure vessel applications.
Super Duplex S32760 Supplier Mumbadevi Steel India (MSI) offers high quality 904L Stainless Steel in forms like Super Duplex Pipe, Super Duplex Tube, Super Duplex Seamless Pipe, Super Duplex Welded Pipe, Super Duplex Tubing, Super Duplex Flange, Super Duplex Pipe Flange, Super Duplex Fasteners, Super Duplex Pipe Fittings, Super Duplex Tube Fittings, Super Duplex Forged Fittings, Super Duplex Sheet, Super Duplex Plate, Super Duplex Sheet Plate, Super Duplex Wire Mesh, Super Duplex Wire, Super Duplex Mesh, Super Duplex Round Bar, Super Duplex Bar, etc. Mumbadevi Steel India (MSI) Specializes in grades like Super Duplex 4501, Super Duplex S32760, Duplex 4501, Super Duplex Stainless Steel, UNS S32760, WNR 1.4501.
Industry Names: Zeron 100, Super Duplex 4501, Duplex 4501, Super Duplex S32760, 25Cr Super Duplex.
Specifications: UNS S32760, WNR 1.4501, F55.
Applications: Oil and gas, Pulp and paper, Power generation, Chemical, Pharmaceutical, Mining, Desalination.
Features: Resistance to pitting and crevice corrosion, Superior resistance to sulfuric acid in many different concentrations, Stress corrosion cracking resistance, Minimum Yield Strength of 80,000 psi, More cost-effective than most nickel based alloys, Outstanding machinability.
Mumbadevi Steel India (MSI) is a leading Supplier, Manufacturer and Exporter of high quality Super Duplex S32760 Stainless Steel with UNS S32760 and WNR 1.4501, in forms like Pipe, Tube, Flange, Fasteners, Fittings, Bars, Sheet, Plate and Wire Mesh. The mills that produce Ni 200 products fulfill the toughest industry standards including those from ASTM, ASME, DIN, and ISO. Super Duplex S32760 is listed in NACE MR 0175 for sour service and having gained ASME Approval for Pressure Vessel applications it can be used in a wide variety of applications.
For more information on Super Duplex S32760 please contact us.
Super Duplex 4501, is a nickel-iron-chromium austenitic alloy that was developed for maximum resistance to acid attack, specifically sulfuric acid. Mumbadevi Steel India (MSI) Supplies high quality Zeron 100 with UNS S32760 and WNR 1.4501.
Other Names: Zeron 100, Super Duplex 4501, Super Duplex S32760, Duplex 4501.
Category: Super Duplex Stainless Steel > Super Duplex UNS S32760.
Material: Super Duplex Stainless Steel
Brand: Mumbadevi Steel India (MSI)
Manufacturer: Mumbadevi Steel India (MSI)
Super Duplex 4501 Specifications and Standards
|Grade||North America||Forging Grade||France||Germany||European||Other Names|
|Super Duplex 4501||UNS S32760||F55||AFNOR Z3CND25.06Az||WNR/DIN 1.4501||EURONORM X2CrNiMoCuWN25.7.4||Super Duplex S32760 / Zeron 100|
Properties of Super Duplex 4501
C P Mn N S Si Cr Ni Mo Cu W PRE* MIN - - - 0.200 - - 24.000 6.000 3.000 0.500 0.500 40.000 MAX 0.030 0.030 1.000 0.300 0.010 1.000 26.000 8.000 4.000 1.000 1.000
(% in 50mm)
MIN 550 750 25.00 MAX 270
Units 20°C 100°C 200°C 300°C Density g/cm³ 7.8 lb/in³ 0.28 Modulus of elasticity GPa 200 194 186 180 psi x 10-6 29 Poissons ratio 0.3 Linear expansion (RT ➞ T)°C x 10-6/°C - 13 13.5 14 Thermal conductivity W/m°C 15 16 17 18 Btu/h ft°F 8.7 Thermal capacity J/kg°C 500 530 560 590 Electric resistivity µΩm 0.8 0.85 0.9 1
