Incoloy 825 Wire Mesh
Mumbadevi Steel India (MSI) is a well-known suppliers and manufacturer of Incoloy 825 Wiremesh. We have stocked one of the best inventories of UNS N08825 Wire Mesh.
Other Names: Incoloy Wire, Incoloy mesh, Incoloy wire mesh
Material: Incoloy 825
Brand: Mumbadevi Steel India (MSI)
Manufacturer: Mumbadevi Steel India (MSI)
Incoloy 825 Wire • Incoloy 825 Wire Mesh Suppliers • Incoloy Welded Wire Mesh • Incoloy Woven Wire Mesh
Incoloy 825 Wire Mesh supplied by Mumbadevi Steel India (MSI) is of high quality and corrosion resistant. The UNS N08825 Wire Mesh, we supply includes a complete range of alloys that demonstrate high strength and high resistance to heat and corrosion in even the most extreme conditions. We have supplied to almost 70 countries worldwide. Having established ourselves and set up our ware-houses near ports, we have built up adequate stock levels of all essential items within our scope of supply and are in position to offer immediate deliveries.
A Wire is a metal drawn out into the form of a thin flexible thread or rod. Mesh is similar to a net in that it has many attached woven or welded strands. Wire mesh is a metallic product that is used across a wide spectrum of applications all over the world. Wire Mesh is a grid formed by welding steel wires together at their intersections. Wire mesh is available in different sizes and types, and each different mesh design can be comprised of varying metals and alloys. Incoloy Wire Mesh is further classified as Welded Wire Mesh and Woven Wire Mesh.
Incoloy Welded Wire Mesh is a grid formed by welding steel wires together at their intersections. Welded steel wire mesh offers greater strength and versatility over woven mesh. Welded mesh will not fray or unravel, is stable and rigid, has a smooth surface and has an excellent aesthetic appearance. Available in a wide range of wire diameters and opening sizes. Incoloy Woven Wire Mesh is a grid formed by weaving wires alternately over and under and are lock-crimped at their intersections. Woven wire mesh is stable and rigid, has a smooth surface and is aesthetically pleasing. Available in a wide range of wire diameters and opening sizes. Incoloy Woven Wire Mesh are further classified into Plain Weave Wire Mesh, Twill Weave Wire Mesh, Dutch Weave Wire Mesh, Crimped Weave Wire Mesh, Three Heddled Weave Wire Mesh, Five Heddled Weave Wire Mesh, Plain Dutch Wire Mesh, Dutch Twill Weave, Twill Dutch Weave, Reverse Dutch Wire Mesh, Reverse Twill Dutch Wire Mesh, Cross Twill Weave.
Mumbadevi Steel India (MSI) is the market leader in the production of Incoloy wire Mesh of welded and woven types. Stainless steel wire mesh has varied applications in construction, food processing, automobile, mining, etc. We have the capacity to manufacture meshes with wires from 1,2 to 12 mm and of any aperture, square or rectangular. The wire mesh we supply conforms to ANSI/AWCI - 01 -1992 and ASTM E 2016-11 and RRW 360 specifications. The thickness of wire mesh is 10 mm To 100 mm Diameter in 100 mm TO 6000 mm in Length. Stainless steel wire mesh is used in a wide variety of industries since it is one of the most common materials for woven wire mesh products besides mild steel and galvanised steel with different properties. Some common applications for stainless steel wire meshes are for instance industrial sieves, chemical filters, architectural decoration, dandy roll sleeves for paper making, dryer belts and conveyor belts for the non-food industry as well as for the food industry.
Mumbadevi Steel India (MSI) have been supplying wire mesh globally since many years. We have exported our products to countries such as UAE, Qatar, USA, Europe, Thailand, South Africa, Japan, Indonesia, Russia, UK, Norway, etc. We have a good reputation amongst all our international clients.
- Wire Mesh Specification: ANSI/AWCI - 01 -1992 and ASTM E 2016-11 and RRW 360
- Thickness Range: 10 mm To 100 mm Diameter in 100 mm TO 6000 mm Length
- Type: Wire Mesh & Wire
- Form: Incoloy 825 Plain Weave, Incoloy 825 Twill Weave, Incoloy 825 Dutch Weave, Incoloy 825 Plain Dutch Wire Mesh, Incoloy 825 Dutch Twill Weave, Incoloy 825 Twill Dutch Weave, Incoloy 825 Reverse Dutch Wire Mesh, Incoloy 825Incoloy 825 Reverse Twill Dutch Wire Mesh, Incoloy 825 Cross Twill Weave
- Surface Finish: Mill Finish, PTFE Coating
- Origin: Indian Origin, European Origin, Japanese Origin
- Testing and Documents: Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, Destructive Test Report, Non Destructive Test Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports
- Packing: Packed in Wooden Boxes, Bubble wraps, Steel Strips Bundled, or as per Customers Requests
Incoloy 825 Alloy Wire Mesh Sizes in Stock
|Type of Wire mesh||Thickness|
|Incoloy Plain Weave, Incoloy Twill Weave, Incoloy Dutch Weave, Incoloy Plain Dutch Wire Mesh, Incoloy Dutch Twill Weave, Incoloy Twill Dutch Weave, Incoloy Reverse Dutch Wire Mesh, Incoloy Reverse Twill Dutch Wire Mesh, Incoloy Cross Twill Weave & Incoloy Wire||10 mm To 100 mm Diameter in 100 mm TO 6000 mm Length|
Forms of UNS N08825 in Stock
Incoloy 825 Wire Available in 10 mm To 100 mm Dia
Incoloy 825 Mesh Available in 10 mm To 100 mm Dia
Welded Wire Mesh
Incoloy 825 Welded Wire Mesh Available in 10 mm To 100 mm Dia
Woven Wire Mesh
Incoloy 825 Woven Wire Mesh Available in 10 mm To 100 mm Dia
Plain Weave Wire Mesh
Incoloy 825 Plain Weave Wire Mesh Available in 10 mm To 100 mm Dia
Twill Weave Wire Mesh
Incoloy 825 Twill Weave Wire Mesh Available in 10 mm To 100 mm Dia
Dutch Weave Wire Mesh
Incoloy 825 Dutch Weave Wire Mesh Available in 10 mm To 100 mm Dia
Crimped Weave Wire Mesh
Incoloy 825 Crimped Weave Wire Mesh Available in 10 mm To 100 mm Dia
Three Heddled Weave Wire Mesh
Incoloy 825 Three Heddled Weave Wire Mesh Available in 10 mm To 100 mm Dia
Five Heddled Weave Wire Mesh
Incoloy 825 Five Heddled Weave Wire Mesh Available in 10 mm To 100 mm Dia
C Ti Mn Fe S Si Cr Ni Cu Mo Al MIN - 0.600 - 22.000 - - 19.500 38.000 1.500 2.500 - MAX 0.050 1.200 1.000 - 0.030 0.500 23.500 46.000 3.000 3.500 0.200
(% in 50mm)
MIN 241 586 30.00 MAX 237
Density lb/in³ 0.294 Mg/m³ 8.14 Specific Heat Btu/lb•°F 0.105 J/kg•°C 440 Melting Range °F 2500-2550 °C 1370-1400 Curie Temperature °F <-320 °C <-196 Permeability 200 oersted (15.9 kA/m) 1.005
Properties of Incoloy 825 alloy
Incoloy 825 Cold Forming
Cold-forming properties and practices are essentially the same for Incoloy alloy 825 as for Inconel alloy 600. Although work-hardening rate is somewhat less than for the common grades of austenitic stainless steels, it is still relatively high. Forming equipment should be well powered and strongly built to compensate for the increase in yield strength with plastic deformation.
Incoloy 825 Hot Forming
The hot-working range for Incoloy alloy 825 is 1600 to 2150°F (870 to 1180°C). For optimum corrosion resistance, final hot working should be done at temperatures between 1600 and 1800°F (870 and 980°C). Cooling after hot working should be air cool or faster. Heavy sections may become sensitized during cooling from the hot-working temperature, and therefore be subject to intergranular corrosion in certain media. A stabilizing anneal restores resistance to corrosion. If material is to be welded or subjected to further thermal treatment and subsequently exposed to an environment that may cause intergranular corrosion, the stabilizing anneal should be performed regardless of cooling rate from the hot-working temperature.
Incoloy 825 Machining
All standard machining operations are readily performed on Incoloy alloy 825. The alloy normally has optimum machining characteristics in the annealed temper.
Incoloy 825 Welding
Incoloy alloy 825 has good weldability by all conventional processes. For most applications, Inconel Welding Electrode 112 for shielded metal-arc welding and Inconel Filler Metal 625 for gas-shielded processes are used. For applications that require highest resistance to corrosion, Inco-weld Welding Electrode 686CPT and Inco-weld Filler Metal 686CPT are used.
Incoloy 825 Heat Treatment
Incoloy 825 is stabilise annealed at 940°C. The softest structure is obtained at 980°C. Sections heavier than sheet, strip and wire should be quenched to avoid sensitisation.
Services We Offer
Documentation is a very important part of the products we supply, and we work continuously to enhance the efficiency of the document-handling process without compromising quality of the product. Documents provided along with the shipment include Certificate of Origin, Material Test Certificate as per EN 10204 3.1 and 10204 3.2, NACE MR10103 and NACE MR0175 certified Test Certificates.
Incoloy Wiremesh are manufactured and controlled to international standards such as ASTM, ASME, BS, MSS, EN, DIN or WERKSTOFFE. Our products undergo stringent quality tests before they are dispatched.
PMI Testing, Ultrasonic Test, Mechanical Testing, Spectro Tests for Chemical Analysis of the grade, Flaring Test, IGC, etc. are some of the tests conducted at our facility. We welcome stage wise inspection from any of your representative or third party inspection agencies.
Packing and Delivery
The product is wrapped and packed in wooden crates or carton boxes. Our primary goal is to deliver quality products in time, no matter where the client is located.
